Making Circles in Python and Julia
This file contains bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
import ArgParse | |
import ImageSegmentation | |
import Images | |
import Luxor | |
import Statistics | |
int_round(f) = round(Int, f) | |
struct Circle{T} | |
x::Int | |
y::Int | |
rgb::T | |
r::Float64 | |
end | |
# Is there a more normal way to do a keyword constructor for a type? | |
function Circle(;x::Int, y::Int, rgb::Tuple{Int64, Int64, Int64}, r::Float64) | |
return Circle(x, y, rgb, r) | |
end | |
function parse_commandline() | |
s = ArgParse.ArgParseSettings() | |
s.exc_handler = ArgParse.debug_handler | |
@ArgParse.add_arg_table s begin | |
"--image", "-i" | |
help = "Path to input image" | |
arg_type = String | |
required = true | |
"--min_radius", "-r" | |
help = "Minimum radius of generated circles" | |
arg_type = Float64 | |
default = 2.0 | |
end | |
return ArgParse.parse_args(s) | |
end | |
function scale(img, target_px) | |
h, w = size(img) | |
# Need sqrt because ratio gets applied in both x and y dimension. | |
return Images.imresize(img, ratio=(target_px / (h*w))^.5) | |
end | |
function segment(img) | |
# k controls segment size. 5 - 500 is a good range | |
# min_size gets rid of small segments | |
return ImageSegmentation.felzenszwalb(img, 60, 100) | |
end | |
function make_mask(label_ix, imgh, imgw) | |
# Create a mask array that's just large enough to contain | |
# the segment we are working on. This will allow the distance transform | |
# to operate the smallest array possible, for speed. | |
pad = Dict(true => 0, false => 1) | |
(top, left), (bottom, right) = map(ix -> ix.I, extrema(label_ix)) | |
# Allocate a pixel-wide boundary strip if we aren't at the image border. | |
top_pad, bottom_pad = pad[top == 1], pad[bottom == imgh] | |
left_pad, right_pad = pad[left == 1], pad[right == imgw] | |
mask = ones(Bool, | |
bottom - top + 1 + top_pad + bottom_pad, | |
right - left + 1 + left_pad + right_pad | |
) | |
new_ix = map(x -> x - CartesianIndex(top - top_pad - 1, left - left_pad - 1), label_ix) | |
mask[new_ix] .= 0 | |
return (left - left_pad, top - top_pad, mask) | |
end | |
function circle_indices(center, radius, height, width) | |
# Code inspired by: | |
# https://github.com/JuliaImages/ImageDraw.jl/blob/master/src/ellipse2d.jl | |
indices = CartesianIndex{2}[] | |
r = CartesianIndex(int_round(radius), int_round(radius)) | |
y, x = center.I | |
# Examine (2*radius + 1)^2 spots, expecting array length ~ pi * radius^2. | |
for ix in center - r: center + r | |
row, col = ix.I | |
if 1 <= row <= height && 1 <= col <= width | |
if (row - y)^2 + (col - x)^2 <= radius^2 | |
push!(indices, ix) | |
end | |
end | |
end | |
return indices | |
end | |
function make_circles(img, seg, min_radius) | |
float2int(f) = round(Int, 256*f) | |
to_clr(l) = float2int.( (l.r, l.g, l.b) ) | |
h, w = size(img) | |
# Add a big circle with the avg color for the background. | |
circles = [Circle( | |
x=int_round(w/2), | |
y=int_round(h/2), | |
rgb= to_clr(Statistics.mean(img)), | |
r=(w*w + h*h)^.5 + 2 | |
)] | |
for label in seg.segment_labels | |
m = findall(x -> x == label, seg.image_indexmap) | |
left, top, mask = make_mask(m, h, w) | |
while true | |
f = Images.feature_transform(mask) | |
edt = Images.distance_transform(f) | |
ix = argmax(edt) | |
r = edt[ix] | |
if r < min_radius || r == Inf | |
break | |
end | |
circle_ix = circle_indices(ix, r, size(edt)...) | |
mask[circle_ix] .= 1 | |
offset_ix = map(x -> x + CartesianIndex(top - 1, left - 1), circle_ix) | |
clr = to_clr(Statistics.mean(img[offset_ix])) | |
y, x = ix.I | |
push!(circles, Circle( | |
x=left + x, | |
y=top + y, | |
rgb=clr, | |
r=r | |
)) | |
end | |
end | |
return circles | |
end | |
function draw(img, circles, filename) | |
h, w = size(img) | |
Luxor.Drawing(w, h, filename) | |
# Paint from biggest to smallest | |
for c in sort(circles, by=c -> c.r, rev=true) | |
r, g, b = map(x -> x / 255, c.rgb) | |
Luxor.setcolor(r, g, b) | |
Luxor.circle(c.x, c.y, c.r - .5, :fill) | |
end | |
Luxor.finish() | |
end | |
function main() | |
args = nothing | |
try | |
args = parse_commandline() | |
println("args", args) | |
catch err | |
args = Dict("image" => "test.jpg", "min_radius" => 2) | |
println("No args supplied, using defaults: ", args) | |
end | |
path = args["image"] | |
name, ext = splitext(basename(path)) | |
println("Loading $(path) ...") | |
@time img = Images.load(path) | |
println("Resizing ...") | |
@time img = scale(img, 1e6) # Downsample to ~1M pixels | |
Images.save("./$(name)-orig.png", img) | |
println("Segmenting ... ") | |
@time seg = segment(img) | |
Images.save("./$(name)-seg.png", map(i-> seg.segment_means[i], seg.image_indexmap)) | |
println("Circling ...") | |
@time circles = make_circles(img, seg, args["min_radius"]) | |
println("Made $(length(circles)) circles") | |
println("Drawing ...") | |
@time draw(img, circles, "./$(name)-circled.png") | |
end | |
if !isinteractive() | |
main() | |
end |
This file contains bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
from scipy import ndimage | |
from skimage import color, io, segmentation, transform | |
from skimage.draw import disk, circle_perimeter_aa, set_color | |
from PIL import Image | |
import argparse | |
import json | |
import numpy as np | |
import os | |
import time | |
int_round = lambda c: int(round(c)) | |
def timed(function): | |
def wrap(*args, **kwargs): | |
start_time = time.time() | |
result = function(*args, **kwargs) | |
end_time = time.time() | |
duration = (end_time- start_time)*1000.0 | |
f_name = function.__name__ | |
print("{} took {:.3f} ms".format(f_name, duration)) | |
return result | |
return wrap | |
@timed | |
def segment(img): | |
return segmentation.felzenszwalb(img, scale=60, min_size=100) | |
def amax(a): | |
"""returns the max of an array, and the coordinates at which it occurs.""" | |
row, col = np.unravel_index(np.argmax(a), a.shape) | |
return a[row][col], (row, col) | |
@timed | |
def scale(img, target_px): | |
"""Scales an input image to have roughly target_px pixels.""" | |
w, h, d = img.shape | |
# Need sqrt below because scale gets applied in both x and y dimension. | |
scale_factor = (float(target_px) / (w*h)) ** .5 | |
nw, nh = int(w * scale_factor), int(h * scale_factor) | |
return transform.resize(img, (nw, nh)) | |
def distance_transform(a, ft, ix): | |
""" | |
a is a binary image of dtype np.int8 | |
ft = np.zeros((input.ndim,) + input.shape, dtype=np.int32) | |
ix = np.indices(input.shape, dtype=ft.dtype) | |
""" | |
ndimage._nd_image.euclidean_feature_transform(a, None, ft) | |
# calculate the distance transform | |
dt = ft - ix | |
np.multiply(dt, dt, dt) # dt *= dt | |
return np.sqrt(dt[0] + dt[1]) | |
def make_mask(labeled_px, label): | |
""" Create a mask array that's just large enough to contain | |
the segment we are working on. This will make the distance transform | |
(the slowest part of this code) much more efficient. | |
""" | |
pad = {True:1, False:0} | |
rows, cols = np.where(labeled_px == label) | |
top, bottom = rows.min(), rows.max() | |
left, right = cols.min(), cols.max() | |
# We need to allocate a pixel-wide boundary strip around this segment | |
# unless we're flush with one of the image sides | |
h, w = labeled_px.shape | |
top_pad, bottom_pad = pad[top != 0], pad[bottom != (h-1)] | |
left_pad, right_pad = pad[left != 0], pad[right != (w-1)] | |
mask = np.zeros(( | |
bottom - top + 1 + top_pad + bottom_pad, | |
right - left + 1 + left_pad + right_pad | |
), dtype='int8') | |
mask[rows - top + top_pad, cols - left + left_pad] = 1 | |
return (left - left_pad, top - top_pad, mask) | |
@timed | |
def make_circles(img, labeled_px, min_radius): | |
# Add a big circle with the avg color for the background. | |
h, w, _ = img.shape | |
circles = [dict( | |
x=int_round(w/2.0), | |
y=int_round(h/2.0), | |
rgb=list(map(int_round, 255*np.average(img, (0, 1)))), | |
r=int_round(2 + (w*w + h*h)**.5) # 2 to account for rounding, being off-center. | |
)] | |
# OK, now make some circles | |
labels = sorted(set(labeled_px.flatten())) | |
for label in labels: | |
left, top, mask = make_mask(labeled_px, label) | |
# preallocate arrays, to avoid a bunch of reallocs | |
indices = np.zeros((mask.ndim,) + mask.shape, dtype='int32') | |
ix = np.indices(mask.shape, dtype='float64') | |
# 1) Compute Euclidean Distance Transform (edt) | |
# 2) For each max in the edt, draw a circle, then zero it out. | |
# 3) repeat until the edt doesn't have entries larger than min_radius | |
while True: | |
edt = distance_transform(mask, indices, ix) | |
r, (row, col) = amax(edt) | |
if r < min_radius: | |
break | |
cr, cc = disk((row, col), r, shape=mask.shape) | |
# Mask out the circle | |
mask[cr, cc] = 0 | |
# Compute average color. Does this need to be done here? | |
clr = list(map(int_round, 255 * np.average(img[ | |
top + cr, | |
left + cc | |
], 0))) | |
# Store painting instructions | |
circles.append(dict(x=int(left + col), y=int(top + row), r=r, rgb=clr)) | |
return circles | |
@timed | |
def draw(img, circles, filename): | |
avg = np.array(list(map(int_round, np.average(img, (0, 1)))), dtype='uint8') | |
out = avg * np.ones(img.shape, dtype='uint8') | |
for c in sorted(circles, key=lambda d: d['r'], reverse=True): | |
x, y, r = c['x'], c['y'], int_round(c['r'] - 1) | |
clr = c['rgb'] | |
# Compute the circle's border, antialiased, then the interior | |
rr, cc, val = circle_perimeter_aa(y, x, r, out.shape) | |
set_color(out, (rr, cc), clr, val) | |
# Interior | |
out[disk((y, x), r, shape=out.shape)] = clr | |
io.imsave(filename, out) | |
@timed | |
def main(filename, min_radius=3): | |
def imsave(s, img): | |
# save a float image without annoying warnings | |
io.imsave(s, (255 * img).astype(np.uint8)) | |
print("Loading %s ..." % filename) | |
img = io.imread(filename) | |
name, ext = os.path.splitext(os.path.basename(filename)) | |
print("Resizing ...") | |
img = scale(img, 1e6) | |
imsave(filename.replace(ext, '-orig.png'), img) | |
print("Segmenting ...") | |
seg = segment(img) | |
labeled_px = color.label2rgb(seg, img, kind='avg', bg_label=-1) | |
imsave(filename.replace(ext, '-seg.png'), labeled_px) | |
print("Circling ...") | |
circles = make_circles(img, seg, min_radius) | |
print("Drawing ...") | |
draw(img, circles, filename.replace(ext, '-circled.png')) | |
print("Saving ...") | |
with open('./%s-circles.json' % name, 'w') as f: | |
json.dump(circles, f, indent=4) | |
if __name__ == '__main__': | |
ap = argparse.ArgumentParser() | |
ap.add_argument("-i", "--image", required=False, default="./test.jpg", | |
help="Path to input image") | |
ap.add_argument("-r", "--min_radius", required=False, default=2, type=float, | |
help="Minimum radius of generated circles") | |
args = vars(ap.parse_args()) | |
main(args['image'], args['min_radius']) |
Total runtime is 2:41.73, broken down as follows:
$ time julia circles.jl
No args supplied, using defaults: Dict{String,Any}("min_radius" => 2,"image" => "test.jpg")
Loading test.jpg ...
1.659704 seconds (4.87 M allocations: 276.811 MiB, 6.11% gc time)
Resizing ...
0.463902 seconds (1.48 M allocations: 93.129 MiB, 3.75% gc time)
Segmenting ...
1.178172 seconds (2.64 M allocations: 242.965 MiB, 11.19% gc time)
Circling ...
143.547013 seconds (1.95 M allocations: 66.293 GiB, 3.88% gc time)
Made 7843 circles
Drawing ...
0.683826 seconds (189.30 k allocations: 12.377 MiB)
julia circles.jl 156.09s user 5.58s system 99% cpu 2:41.73 total
Python timing is 17.7 seconds faster on the same machine:
$ time python circles.py
Loading ./test.jpg ...
Resizing ...
scale took 350.042 ms
Segmenting ...
segment took 1878.778 ms
Circling ...
make_circles took 135736.593 ms
Drawing ...
draw took 1844.562 ms
Saving ...
main took 142669.479 ms
python circles.py 138.25s user 5.17s system 99% cpu 2:24.03 total
posted about this on the Julia discourse
Nice script!
Sign up for free
to join this conversation on GitHub.
Already have an account?
Sign in to comment
Here is the test image, test.jpg:
