Ruby on Rails Training (part 2) – Rails

Table of Contents

TBD

---

Getting started with Rails

---

Rails Guides (https://guides.rubyonrails.org)

For more information about Rails, we highly recommend that you peruse the official Getting Started guides. The most useful sections are linked here:

• ActiveRecord — Rails Object-Relational Mapping
  • Active Record Basics
  • Active Record Migrations — constructing your db schema through Rails
  • Active Record Associations — the "relationial" part of the ORM
  • Active Record Query Interface — Rails DSL for querying the backing database
• Views — HTML Rendering
  • Action View Overview
  • Layout and Rendering
• Controllers — RESTful Logic
  • Action Controller Overview
  • Rails Routing

---

Building a Demo App

We are going to use Ruby 2.5 and Rails 6.

To start, make a directory named rails-test, then create the following file inside of it:

# rails-test/Dockerfile

FROM ruby:2.5

RUN apt-get update && \
    apt-get install -y --no-install-recommends \
        nodejs npm

RUN npm update && npm install -g yarn

RUN gem update --system && \
    gem install rake && \
    gem install bundler && \
    gem install rails

WORKDIR /usr/src/app

RUN rails new . && bundle install

EXPOSE 3000
CMD bundle exec rails server -b 0.0.0.0

cd rails-test

docker build -t rails-test .

docker run -it --rm -v $(pwd)/.:/usr/src/app rails-test bash -c "rails new . && bundle install && bundle exec rails webpacker:install"

docker run -it --rm -p 3000:3000 -v $(pwd)/.:/usr/src/app rails-test

---

Rails Apps are All-in-One Webserver Environments

---

Directory Structure

Rails apps begin with the following datastructure:

.
│
├── app
│    ├── assets
│    │    ├── images
│    │    ├── javascripts
│    │    │    └── application.js
│    │    |
│    │    └── stylesheets
│    │        └── application.css
│    │
│    ├── controllers
│    │    ├── application_controller.rb
│    │    └── concerns
│    │
│    ├── helpers
│    │    └── application_helper.rb
│    │
│    ├── mailers
│    ├── models
│    │    └── concerns
│    │
│    └── views
│        └── layouts
│            └── application.html.erb
│
├── bin
│    ├── bundle
│    ├── rails
│    ├── rake
│    ├── setup
│    └── spring
│
├── config
│    ├── application.rb
│    ├── boot.rb
│    ├── database.yml
│    ├── environment.rb
│    ├── environments
│    │    ├── development.rb
│    │    ├── production.rb
│    │    └── test.rb
│    │
│    ├── initializers
│    │    ├── assets.rb
│    │    ├── backtrace_silencers.rb
│    │    ├── cookies_serializer.rb
│    │    ├── filter_parameter_logging.rb
│    │    ├── inflections.rb
│    │    ├── mime_types.rb
│    │    ├── session_store.rb
│    │    └── wrap_parameters.rb
│    │
│    ├── locales
│    │    └── en.yml
│    │
│    ├── routes.rb
│    └── secrets.yml
│
├── config.ru
├── db
│    └── seeds.rb
│
├── Gemfile
├── Gemfile.lock
├── lib
│    ├── assets
│    └── tasks
│
├── log
├── public
│    ├── 404.html
│    ├── 422.html
│    ├── 500.html
│    ├── favicon.ico
│    └── robots.txt
│
├── Rakefile
├── README.rdoc
├── test
│    ├── controllers
│    ├── fixtures
│    ├── helpers
│    ├── integration
│    ├── mailers
│    ├── models
│    └── test_helper.rb
│
├── tmp
│    └── cache
│         └── assets
│
└── vendor
     └── assets
          ├── javascripts
          └── stylesheets

Location	Description
app	Core directory of the entire app; most of the application-specific code will go into this directory.
app/assets	Contains the static files required for the application’s front-end grouped into folders based on their type.
app/controllers	Controllers are responsible for orchestrating the model and views. Controllers handle the logic of parsing queries.
app/controllers/application_controller.rb	This is the main controller from which all other controllers inherit. The methods on ApplicationController are available to other controllers as well. This controller inherits from the ActionController::Base module, which has set of methods to work with in controllers.
app/helpers	This is where all the helper functions for views reside.
app/controllers/application_helper.rb	Similar to the ApplicationController, This is the main helper from which all other helpers inherit.
app/models	All model files live in the app/models directory. Models act as object-relational maps to the database tables that hold the application data.
app/views	Files related to Views (HTML templates used to render webpages) go into this directory. The files are a combination of HTML and Ruby (called Embedded Ruby or Erb) and are organized based on the controller to which they correspond. There is a view file for each controller action.
config	As the name suggests this contains all the application’s configuration files. The database connection and application behavior can be altered by the files inside this directory.
config/environments	This folder contains the environment-specific configuration files for the development, test, and production environments.
config/initializers	Any *.rb file you create here will run during the Rails initialization, automatically.
db	All the database related files go inside this folder. The configuration, schema, and migration files can be found here, along with any seed files.
Gemfile	The Gemfile is the place where all your app’s gem dependencies are declared. This file is mandatory, as it includes the Rails core gems, among other gems.
Gemfile.lock	Gemfile.lock holds the gem dependency tree, including all versions, for the app. This file is generated by bundle install on the above Gemfile. It, in effect, locks your app dependencies to specific versions.
lib	This directory is where all the application specific libraries goes. Application specific libraries are re-usable generic code extracted from the application.
log	This holds all the log files. Rails automatically creates files for each environment.
test	The folder name says it all. This holds all the test files for the app. A subdirectory is created for each component’s test files.

---

Rails ActiveRecord

In Active Record, objects carry both persistent data and behavior which operates on that data. Active Record takes the opinion that ensuring data access logic as part of the object will educate users of that object on how to write to and read from the database.

Another way of thinking about it is that Active Record lets you create a Ruby object that represents a row in one of your database tables (such as a User):

User.new(name: "Harold", surname: "Riddler", age: 37)

    ...

u = User.find_by(surname: "Riddler")
u.age += 1
u.save

Rails ActiveRecord is, as the name implies, an implementation of the "active record" architectural pattern.

---

Models

Rails leverages Object Relational Mapping via "Models" to connect objects in your app to the tables described in your schema.

Suppose that you wanted to create an online e-reader app. Perhaps you want users to be able to navigate directly to a particular chapter, with each chapter containing a link to the next, and each "book" containing a list of chapters. Let's start by creating the basic "chunk" of our service, the Chapter:

class Chapter < ApplicationRecord
  belongs_to :book
end

Our Chapter Model now contains only one line: the belongs_to statement is known as an "Association". This declaration simply says "each chapter belongs to one book" and corresponds to the book_id foreign key in our Chapters table.

However, Rails wants us to also add a reference on the other side of the association:

class Book < ApplicationRecord
  has_many :chapters
  validates :title, presence: true
end

These two declarations enable a good bit of automatic behavior. For example, if you have an instance variable @book containing a Book, you can retrieve all the Chapters belonging to that Book as an array using @book.chapters. The validates declaration simply ensures that any new Book is provided a "title" argument.

There are four main forms of association:

Association	Usage Example	Relationship
belongs_to	@book.owner	one-to-one
has_one	@book.jacket	one-to-one
has_many	@book.chapters	one-to-many
has_and_belongs_to_many	@book.authors	many-to-many

class Book < ApplicationRecord
    belongs_to :owner
    has_one :jacket
    has_many :chapters
    has_and_belongs_to_many :authors
end

class Jacket < ApplicationRecord
    belongs_to :book
end

class Chapter < ApplicationRecord
    belongs_to :book
end

class Author < ApplicationRecord
    has_many :books
end

For more information about ActiveRecord Associations, take a look at the ActiveRecord Guide.

---

The generate Command

Rails provides a convenient CLI templating mechanism via the the generate command:

$ rails generate scaffold Book author:string title:string

This command will generate several files, including:

File	Purpose
db/migrate/[datetime]_create_books.rb	Migration to create the Books table in your database
app/controllers/books_controller.rb	The Book controller
app/models/book.rb	The Book model
app/views/_books.html.erb	The Book view
test/controllers/books_controller_test.rb	Testing harness for the Books controller
test/models/book_test.rb	Testing harness for the Book model
test/fixtures/books.yml	Sample Books for use in testing

To create Models that relate to each other, we simple add a reference attribute:

$ rails generate Model Chapter number:integer body:text book:references

This templating command will generate a similar set of files:

File	Purpose
db/migrate/[datetime]_create_chapters.rb	Migration to create the Chapter table in your database
app/models/chapter.rb	The Chapter model
test/models/chapter_test.rb	Testing harness for the Chapter model
test/fixtures/chapters.yml	Sample Chapters for use in testing

Notice that the scaffold generation added an extra controller and a view file for the Book model. These files manage the RESTful API and the HTML response, respectively.

Let's look at what those files do:

---

Migrations

Migrations are Ruby classes that are designed to make it simple to create and modify database tables. Rails uses rake commands to run migrations, and it's possible to undo a migration after it's been applied to your database. Migration filenames include a timestamp to ensure that they're processed in the order that they were created.

Let's look at the create_books migration

class CreateBooks < ActiveRecord::Migration[6.0]
  def change
    create_table :books do |t|
      t.string :author
      t.string :title

      t.timestamps
    end
  end
end

With just this one migration file, we could create a Books table via

$ rails db:migrate

which yields something like

==  CreateBooks: migrating ==================================================
-- create_table(:books)
   -> 0.0019s
==  CreateBooks: migrated (0.0020s) =========================================

However, we have created more than one migration file. In its most basic form, migrate runs the change or up methods for all the migrations that have not yet been run.

Let's look at the second migration

class CreateChapters < ActiveRecord::Migration[6.0]
  def change
    create_table :chapters do |t|
      t.integer :number
      t.text :body
      t.references :book, null: false, foreign_key: true

      t.timestamps
    end
  end
end

The t.references line creates an integer column called book_id, an index for it, and a foreign key constraint that points to the id column of the books table. Let's look at the rest of our migration:

==  CreateChapters: migrating =================================================
-- create_table(:chapters)
   -> 0.0115s
==  CreateChapters: migrated (0.0119s) ========================================

At this point, our database schema is outlined in the db/schema.rb file:

ActiveRecord::Schema.define(version: 20190114194744) do

  create_table "book_chapters", force: :cascade, options: "ENGINE=InnoDB DEFAULT CHARSET=utf8" do |t|
    t.integer "number"
    t.text "body"
    t.datetime "created_at", null: false
    t.datetime "updated_at", null: false
    t.bigint "book_id"
    t.index ["book_id"], name: "index_book_chapters_on_book_id"
  end

  create_table "books", force: :cascade, options: "ENGINE=InnoDB DEFAULT CHARSET=utf8" do |t|
    t.string "author"
    t.string "title"
    t.datetime "created_at", null: false
    t.datetime "updated_at", null: false
  end

end

[color=#FF0000] N.B. the schema.rb is generated by the migrate command to reflect the current state of your database. Modifying this file will not result in any changes to your db.

---

Rails Actions

---

Routing and Controllers

Routes tell the application how to "wire" an HTTP request to a Controller. By default routes are handled in /config/routes.rb. Controllers turn these requests into specific actions or data. Controllers can respond in many ways including json, xml, and html.

In the routes.rb file, you can specify new routes, optionally with specific parameters:

# Send GET HTTP requests from /patients url
# to the `index` method of the `patients`
# controller.
get '/patients', to: 'patients#index'

# Send GET HTTP requests from /patients/1 to
# the `show` method of the `patients`
# controller.
get '/patients/:id', to: 'patients#show'

The controller then gains access to the provided route- and query-parameters

class PatientsController < ApplicationController
  def index
    @books = Patient.all
  end

  def show
    @patient = Patient.find id: params[:id]
  end
end

---

Params

The params hash is a copy of variables from the POST body, the GET query, and the URL path (listed here in order of precedence, lowest to highest).

---

RESTing our Resources

In Rails, a resourceful route provides a mapping between HTTP verbs and URLs to controller actions. By convention, each action also maps to a specific CRUD operation in a database. A single entry in the routing file, such as:

resources :photos

creates seven different routes in your application, all mapping to the Photos controller:

HTTP Verb	Path	Controller#Action	Used for
GET	/photos	photos#index	display a list of all photos
GET	/photos/new	photos#new	return an HTML form for creating a new photo
POST	/photos	photos#create	create a new photo
GET	/photos/:id	photos#show	display a specific photo
GET	/photos/:id/edit	photos#edit	return an HTTML form for editing a photo
PATCH/PUT	/photos/:id	photos#update	update a specific photo
DELETE	/photos/:id	photos#destroy	delete a specific photo

Resources can be nested to simplify object-relationships:

resources :authors do
  resources :books, only: [:index, :new, :create]
end
resources :books, only: [:show, :edit, :update, :destroy]

By only nesting the #index, #new, and #create actions under the authors route, we can simplify cumbersome paths:

[GET] /authors/1/books/5/edit

# instead of the nested route above, we simplify to

[GET] /books/5/edit

[color=#FF0000] N.B. it is generally a good rule of thumb that resources should never be nested more than 1 level deep. You can read more about why this is, by following this finely crafted link.

You are not limited to the default RESTful routes that Resources provide! If you like, you may add additional routes that apply to specific routes.

---

Views

The default templating language for Rails is called ERB (Embedded Ruby).

ERB files are run in the context of a Rails controller. They are just simple text files with ruby embedded certain tags. This ruby is

<% Ruby code -- inline with output %>
<%= Ruby expression -- replace with result %>
<%# comment -- ignored -- useful in testing %>
% a line of Ruby code -- treated as <% line %>
%% replaced with % if first thing on a line and % processing is used
<%% or %%> -- replace with <% or %> respectively

---

Naming Conventions

Taken from github user iangreenleaf

General Ruby conventions

Class names are CamelCase.

Methods and variables are snake_case.

Methods with a ? suffix will return a boolean.

Methods with a ! suffix mean one of two things: either the method operates destructively in some fashion, or it will raise and exception instead of failing (such as Rails models' #save! vs. #save).

In documentation, ::method_name denotes a class method, while #method_name denotes a instance method.

Database

Database tables use snake_case. Table names are plural.

Column names in the database use snake_case, but are generally singular.

Example:

+--------------------------+
| bigfoot_sightings        |
+------------+-------------+
| id         | ID          |
| sighted_at | DATETIME    |
| location   | STRING      |
| profile_id | FOREIGN KEY |
+------------+-------------+

+------------------------------+
| profiles                     |
+---------------------+--------+
| id                  | ID     |
| name                | STRING |
| years_of_experience | INT    |
+---------------------+--------+

Model

Model class names use CamelCase. These are singular, and will map automatically to the plural database table name.

Model attributes and methods use snake_case and match the column names in the database.

Model files go in app/models/#{singular_model_name}.rb.

Example:

# app/models/bigfoot_sighting.rb
class BigfootSighting < ActiveRecord::Base
  # This class will have these attributes: id, sighted_at, location
end

# app/models/profile.rb
class Profile < ActiveRecord::Base
  # Methods follow the same conventions as attributes
  def veteran_hunter?
    years_of_experience > 2
  end
end

Relations in models

Relations use snake_case and follow the type of relation, so has_one and belongs_to are singular while has_many is plural.

Rails expects foreign keys in the database to have an _id suffix, and will map relations to those keys automatically if the names line up.

Example:

# app/models/bigfoot_sighting.rb
class BigfootSighting < ActiveRecord::Base
  # This knows to use the profile_id field in the database
  belongs_to :profile
end

# app/models/profile.rb
class Profile < ActiveRecord::Base
  # This knows to look at the BigfootSighting class and find the foreign key in that table
  has_many :bigfoot_sightings
end

Controllers

Controller class names use CamelCase and have Controller as a suffix. The Controller suffix is always singular. The name of the resource is usually plural.

Controller actions use snake_case and usually match the standard route names Rails defines (index, show, new, create, edit, update, delete).

Controller files go in app/controllers/#{resource_name}_controller.rb.

Example:

# app/controllers/bigfoot_sightings_controller.rb
BigfootSightingsController < ApplicationController
  def index
    # ...
  end
  def show
    # ...
  end
  # etc
end

# app/controllers/profiles_controller.rb
ProfilesController < ApplicationController
  def show
    # ...
  end
  # etc
end

Routes

Route names are snake_case, and usually match the controller. Most of the time routes are plural and use the plural resources.

Singular routes are a special case. These use the singular resource and a singular resource name. However, they still map to a plural controller by default!

Example:

resources :bigfoot_sightings
# Users can only see their own profiles, so we'll use `/profile` instead
# of putting an id in the URL.
resource :profile

Views

View file names, by default, match the controller and action that they are tied to.

Views go in app/views/#{resource_name}/#{action_name}.html.erb.

Examples:

• app/views/bigfoot_sightings/index.html.erb
• app/views/bigfoot_sightings/show.html.erb
• app/views/profile/show.html.erb

More resources

• ActiveRecord naming and schema conventions (including magic column names)
• Mind map of Rails conventions
