I'm trying to create an API to describe an OpenGL Shader Pipeline in Zig. The goal of all this is to have type-safe functions for e.g. setting uniforms and automatically generating variable declarations based on the types.

My current (semi-working) implementation looks like this:
Edit: Actually, it's working, but there's still a lot of stuff done by manually calling the OpenGL functions (like setting uniforms). So basically only the code generation is being used right now.

/// For now it only supports vertex and fragment shaders.
/// At some point a generic Stage type could be created which would
/// contain the information about input and output. This allows
/// for creating arbitrary pipelines where Tesselation/Geometry shaders
/// can easily be added or removed.
pub const Pipeline = struct {
    Vertex: type,
    Uniforms: type,
    Varyings: type,

    /// These contain the source code of the shader
    /// as written by the user
    vertex_shader: []const u8,
    fragment_shader: []const u8,

    /// This function puts together the actual code that gets passed to glShaderSource from
    /// the user code, Vertex-Type, Uniform-Type, etc. and does the OpenGL setup.
    pub fn compile(comptime self: Pipeline, allocator: *Allocator) ShaderProgram
};

// As you can see, this is rather sparse right now, which is the reason
// so much stuff still has to be done manually.
pub const ShaderProgram = struct {
    gl_id: u32, // OpenGL GLuint
};

The result of calling Pipeline.compile can then be used to create a Mesh that is rendered with the compiled program.

pub const Mesh = struct {
    pub fn create(program: ShaderProgram) Mesh

    // Functions to draw the mesh or use it in some other way. You get the idea
    pub fn draw() void
};

I'm not really experienced with OpenGL so it could very well be that I am trying to use it in a way it's not supposed to be used.

---

Example

A small, non-working excerpt from my code :)

/// The Pipeline
const test_pipeline = Pipeline {
    .Vertex = struct {
        aPosition: Vec2,
        aColor: Vec3,
    },
    .Uniforms = struct {
        uProjection: Mat3,
        uModel: Mat3,
        uScale: Vec2
    },
    .Varyings = struct {
        fColor: Vec3
    },

    vertex_shader =
        \\void main()
        \\  vec3 position = uProjection * uModel * vec3(aPosition * uScale, 1.0);
        \\
        \\  fColor = aColor;
        \\
        \\  gl_Position = vec4(position, 1.0)
        \\}
        ,

    .fragment_shader =
        \\void main() {
        \\  outColor = vec4(fColor, 1.0);
        \\}
};

// Later, when creating the mesh
const program = test_pipeline.compile(std.debug.global_allocator);
const mesh = Mesh.create(program);

// Set uniforms (projection matrix, etc.)
// ...

// Render the mesh
mesh.draw();

Here's a gif of the running application, which is just a triangle that can be moved around using WASD.

---

The generated shader code looks like this:

Vertex Shader

#version 330
in vec2 aPosition;
in vec3 aColor;

uniform mat3 uProjection;
uniform mat3 uModel;
uniform vec2 uScale;

out vec3 fColor;

void main() {
  vec3 position = uProjection * uModel * vec3(aPosition * uScale, 1.0);

  fColor = aColor;

  gl_Position = vec4(position, 1.0);
}

Fragment Shader

#version 330
in vec3 fColor;

uniform mat3 uProjection;
uniform mat3 uModel;
uniform vec2 uScale;

out vec4 outColor;

void main() {
  outColor = vec4(fColor, 1.0);
}
