Runcinated tesseract - tetrahedra only

runcinatedTesseract.md

runcinatedTesseract.pov

// runcinated tesseract - tetrahedra only //
#version 3.7;

global_settings { assumed_gamma 1 }

#include "colors.inc"
#include "textures.inc"
#include "glass.inc"

// camera ----------------------------------------------------------------------
camera {
    location <0, 0,-10>
    look_at 0
    angle 45
    right x*image_width/image_height
}

// light -----------------------------------------------------------------------
light_source { <0, 0,-100> color White shadowless }

// space -----------------------------------------------------------------------
#declare D = .5;
sky_sphere {
  pigment {
    crackle
    color_map {
      [pow(0.5, D) color Black]
      [pow(0.6, D) color White*10]
    }
    scale .005/D
  }
}

// vertices --------------------------------------------------------------------
#declare nvertices = 64;
#declare vertices = array[nvertices]
  {
    <-1, -1, -1, -1 - sqrt(2)>,
    <1, -1, -1, -1 - sqrt(2)>,
    <-1, 1, -1, -1 - sqrt(2)>,
    <1, 1, -1, -1 - sqrt(2)>,
    <-1, -1, 1, -1 - sqrt(2)>,
    <1, -1, 1, -1 - sqrt(2)>,
    <-1, 1, 1, -1 - sqrt(2)>,
    <1, 1, 1, -1 - sqrt(2)>,
    <-1, -1, -1, 1 + sqrt(2)>,
    <1, -1, -1, 1 + sqrt(2)>,
    <-1, 1, -1, 1 + sqrt(2)>,
    <1, 1, -1, 1 + sqrt(2)>,
    <-1, -1, 1, 1 + sqrt(2)>,
    <1, -1, 1, 1 + sqrt(2)>,
    <-1, 1, 1, 1 + sqrt(2)>,
    <1, 1, 1, 1 + sqrt(2)>,
    <-1, -1, -1 - sqrt(2), -1>,
    <1, -1, -1 - sqrt(2), -1>,
    <-1, 1, -1 - sqrt(2), -1>,
    <1, 1, -1 - sqrt(2), -1>,
    <-1, -1, 1 + sqrt(2), -1>,
    <1, -1, 1 + sqrt(2), -1>,
    <-1, 1, 1 + sqrt(2), -1>,
    <1, 1, 1 + sqrt(2), -1>,
    <-1, -1, -1 - sqrt(2), 1>,
    <1, -1, -1 - sqrt(2), 1>,
    <-1, 1, -1 - sqrt(2), 1>,
    <1, 1, -1 - sqrt(2), 1>,
    <-1, -1, 1 + sqrt(2), 1>,
    <1, -1, 1 + sqrt(2), 1>,
    <-1, 1, 1 + sqrt(2), 1>,
    <1, 1, 1 + sqrt(2), 1>,
    <-1, -1 - sqrt(2), -1, -1>,
    <1, -1 - sqrt(2), -1, -1>,
    <-1, 1 + sqrt(2), -1, -1>,
    <1, 1 + sqrt(2), -1, -1>,
    <-1, -1 - sqrt(2), 1, -1>,
    <1, -1 - sqrt(2), 1, -1>,
    <-1, 1 + sqrt(2), 1, -1>,
    <1, 1 + sqrt(2), 1, -1>,
    <-1, -1 - sqrt(2), -1, 1>,
    <1, -1 - sqrt(2), -1, 1>,
    <-1, 1 + sqrt(2), -1, 1>,
    <1, 1 + sqrt(2), -1, 1>,
    <-1, -1 - sqrt(2), 1, 1>,
    <1, -1 - sqrt(2), 1, 1>,
    <-1, 1 + sqrt(2), 1, 1>,
    <1, 1 + sqrt(2), 1, 1>,
    <-1 - sqrt(2), -1, -1, -1>,
    <1 + sqrt(2), -1, -1, -1>,
    <-1 - sqrt(2), 1, -1, -1>,
    <1 + sqrt(2), 1, -1, -1>,
    <-1 - sqrt(2), -1, 1, -1>,
    <1 + sqrt(2), -1, 1, -1>,
    <-1 - sqrt(2), 1, 1, -1>,
    <1 + sqrt(2), 1, 1, -1>,
    <-1 - sqrt(2), -1, -1, 1>,
    <1 + sqrt(2), -1, -1, 1>,
    <-1 - sqrt(2), 1, -1, 1>,
    <1 + sqrt(2), 1, -1, 1>,
    <-1 - sqrt(2), -1, 1, 1>,
    <1 + sqrt(2), -1, 1, 1>,
    <-1 - sqrt(2), 1, 1, 1>,
    <1 + sqrt(2), 1, 1, 1>
  };

// rotated and projected vertices ----------------------------------------------
#macro rotate4d(theta,phi,xi,vec)
    #local a = cos(xi);
    #local b = sin(theta)*cos(phi)*sin(xi);
    #local c = sin(theta)*sin(phi)*sin(xi);
    #local d = cos(theta)*sin(xi);
    #local p = vec.x;
    #local q = vec.y;
    #local r = vec.z;
    #local s = vec.t;
    < a*p - b*q - c*r - d*s
    , a*q + b*p + c*s - d*r
    , a*r - b*s + c*p + d*q
    , a*s + b*r - c*q + d*p >
#end

#macro StereographicProjection(q)
    #local h = 25.8;
    acos(q.t/sqrt(h))/pi*<q.x,q.y,q.z>/sqrt(h-q.t*q.t)
#end

#macro Vertices3(theta,phi,xi)
    #local out = array[nvertices];
    #for(i,0,nvertices-1)
        #local out[i] = StereographicProjection(
                            rotate4d(theta,phi,xi,vertices[i])
                        );
    #end
    out
#end

// macro draw Tetrahedron ------------------------------------------------------
#declare edgeTexture = texture {
    Gold_Metal
    finish {
        phong 1
        ambient .1
        diffuse .9
        reflection 0
        specular .1
        metallic
    }
};

#macro edge(i,j)
    cylinder {
        rvs[i] rvs[j], 0.0035
        texture {
            edgeTexture
        }
    }
#end

#macro drawTetrahedron(i, j, k, l, Tex)
    triangle { rvs[i], rvs[j], rvs[k]
    	texture { Tex finish{ reflection 0 } }
    }
    triangle { rvs[i], rvs[j], rvs[l]
    	texture { Tex finish{ reflection 0 } }
    }
    triangle { rvs[i], rvs[k], rvs[l]
    	texture { Tex finish{ reflection 0 } }
    }
    triangle { rvs[j], rvs[k], rvs[l]
    	texture { Tex finish{ reflection 0 } }
    }
    edge(i,j)
    edge(i,k)
    edge(i,l)
    edge(j,k)
    edge(j,l)
    edge(k,l)
    sphere {
        rvs[i], 0.005
        texture { edgeTexture }
    }
    sphere {
        rvs[j], 0.005
        texture { edgeTexture }
    }
    sphere {
        rvs[k], 0.005
        texture { edgeTexture }
    }
    sphere {
        rvs[l], 0.005
        texture { edgeTexture }
    }
#end

// draw ------------------------------------------------------------------------
#declare rvs = Vertices3(pi/2, pi/2, 2*frame_number*pi/180);

object {
    union {
        drawTetrahedron(38, 22, 6, 54, texture{Ruby_Glass})
        drawTetrahedron(30, 14, 46, 62, texture{Ruby_Glass})
        drawTetrahedron(63, 31, 47, 15, texture{Ruby_Glass})
        drawTetrahedron(39, 55, 7, 23, texture{Ruby_Glass})
        drawTetrahedron(26, 10, 42, 58, texture{Ruby_Glass})
        drawTetrahedron(32, 16, 0, 48, texture{Ruby_Glass})
        drawTetrahedron(19, 35, 51, 3, texture{Ruby_Glass})
        drawTetrahedron(44, 12, 28, 60, texture{Ruby_Glass})
        drawTetrahedron(27, 59, 43, 11, texture{Ruby_Glass})
        drawTetrahedron(18, 2, 50, 34, texture{Ruby_Glass})
        drawTetrahedron(45, 29, 61, 13, texture{Ruby_Glass})
        drawTetrahedron(33, 17, 1, 49, texture{Ruby_Glass})
        drawTetrahedron(41, 25, 9, 57, texture{Ruby_Glass})
        drawTetrahedron(37, 5, 53, 21, texture{Ruby_Glass})
        drawTetrahedron(40, 24, 56, 8, texture{Ruby_Glass})
        drawTetrahedron(36, 4, 52, 20, texture{Ruby_Glass})
    }
    scale 9
}

runcinatedTesseract_stereographic.pov

// stereographic runcinated tesseract - tetrahedra only //
#version 3.7;

global_settings { assumed_gamma 1 }

#include "colors.inc"
#include "textures.inc"

// camera ----------------------------------------------------------------------
camera {
    location <0, 0,-10>
    look_at 0
    angle 45
    right x*image_width/image_height
}

// light -----------------------------------------------------------------------
light_source { <0, 0, -1000> color White shadowless }

// space -----------------------------------------------------------------------
#declare D = .5;
sky_sphere {
  pigment {
    crackle
    color_map {
      [pow(0.5, D) color Black]
      [pow(0.6, D) color White*10]
    }
    scale .005/D
  }
}

// vertices --------------------------------------------------------------------
#declare nvertices = 64;
#declare vertices = array[nvertices]
  {
    <-1, -1, -1, -1 - sqrt(2)>,
    <1, -1, -1, -1 - sqrt(2)>,
    <-1, 1, -1, -1 - sqrt(2)>,
    <1, 1, -1, -1 - sqrt(2)>,
    <-1, -1, 1, -1 - sqrt(2)>,
    <1, -1, 1, -1 - sqrt(2)>,
    <-1, 1, 1, -1 - sqrt(2)>,
    <1, 1, 1, -1 - sqrt(2)>,
    <-1, -1, -1, 1 + sqrt(2)>,
    <1, -1, -1, 1 + sqrt(2)>,
    <-1, 1, -1, 1 + sqrt(2)>,
    <1, 1, -1, 1 + sqrt(2)>,
    <-1, -1, 1, 1 + sqrt(2)>,
    <1, -1, 1, 1 + sqrt(2)>,
    <-1, 1, 1, 1 + sqrt(2)>,
    <1, 1, 1, 1 + sqrt(2)>,
    <-1, -1, -1 - sqrt(2), -1>,
    <1, -1, -1 - sqrt(2), -1>,
    <-1, 1, -1 - sqrt(2), -1>,
    <1, 1, -1 - sqrt(2), -1>,
    <-1, -1, 1 + sqrt(2), -1>,
    <1, -1, 1 + sqrt(2), -1>,
    <-1, 1, 1 + sqrt(2), -1>,
    <1, 1, 1 + sqrt(2), -1>,
    <-1, -1, -1 - sqrt(2), 1>,
    <1, -1, -1 - sqrt(2), 1>,
    <-1, 1, -1 - sqrt(2), 1>,
    <1, 1, -1 - sqrt(2), 1>,
    <-1, -1, 1 + sqrt(2), 1>,
    <1, -1, 1 + sqrt(2), 1>,
    <-1, 1, 1 + sqrt(2), 1>,
    <1, 1, 1 + sqrt(2), 1>,
    <-1, -1 - sqrt(2), -1, -1>,
    <1, -1 - sqrt(2), -1, -1>,
    <-1, 1 + sqrt(2), -1, -1>,
    <1, 1 + sqrt(2), -1, -1>,
    <-1, -1 - sqrt(2), 1, -1>,
    <1, -1 - sqrt(2), 1, -1>,
    <-1, 1 + sqrt(2), 1, -1>,
    <1, 1 + sqrt(2), 1, -1>,
    <-1, -1 - sqrt(2), -1, 1>,
    <1, -1 - sqrt(2), -1, 1>,
    <-1, 1 + sqrt(2), -1, 1>,
    <1, 1 + sqrt(2), -1, 1>,
    <-1, -1 - sqrt(2), 1, 1>,
    <1, -1 - sqrt(2), 1, 1>,
    <-1, 1 + sqrt(2), 1, 1>,
    <1, 1 + sqrt(2), 1, 1>,
    <-1 - sqrt(2), -1, -1, -1>,
    <1 + sqrt(2), -1, -1, -1>,
    <-1 - sqrt(2), 1, -1, -1>,
    <1 + sqrt(2), 1, -1, -1>,
    <-1 - sqrt(2), -1, 1, -1>,
    <1 + sqrt(2), -1, 1, -1>,
    <-1 - sqrt(2), 1, 1, -1>,
    <1 + sqrt(2), 1, 1, -1>,
    <-1 - sqrt(2), -1, -1, 1>,
    <1 + sqrt(2), -1, -1, 1>,
    <-1 - sqrt(2), 1, -1, 1>,
    <1 + sqrt(2), 1, -1, 1>,
    <-1 - sqrt(2), -1, 1, 1>,
    <1 + sqrt(2), -1, 1, 1>,
    <-1 - sqrt(2), 1, 1, 1>,
    <1 + sqrt(2), 1, 1, 1>
  };

// tetrahedra ------------------------------------------------------------------
#declare tetrahedra = array[16][4]
    {
        {38, 22, 6, 54},
        {30, 14, 46, 62},
        {63, 31, 47, 15},
        {39, 55, 7, 23},
        {26, 10, 42, 58},
        {32, 16, 0, 48},
        {19, 35, 51, 3},
        {44, 12, 28, 60},
        {27, 59, 43, 11},
        {18, 2, 50, 34},
        {45, 29, 61, 13},
        {33, 17, 1, 49},
        {41, 25, 9, 57},
        {37, 5, 53, 21},
        {40, 24, 56, 8},
        {36, 4, 52, 20}
    };

// tetrahedra faces (triangles) ################################################
#declare faces = array[64][3];
#for(i, 0, 15)
    #declare faces[4*i][0] = tetrahedra[i][0];
    #declare faces[4*i][1] = tetrahedra[i][1];
    #declare faces[4*i][2] = tetrahedra[i][2];
    #declare faces[4*i+1][0] = tetrahedra[i][0];
    #declare faces[4*i+1][1] = tetrahedra[i][1];
    #declare faces[4*i+1][2] = tetrahedra[i][3];
    #declare faces[4*i+2][0] = tetrahedra[i][0];
    #declare faces[4*i+2][1] = tetrahedra[i][2];
    #declare faces[4*i+2][2] = tetrahedra[i][3];
    #declare faces[4*i+3][0] = tetrahedra[i][1];
    #declare faces[4*i+3][1] = tetrahedra[i][2];
    #declare faces[4*i+3][2] = tetrahedra[i][3];
#end

// edges -----------------------------------------------------------------------
#declare edges = array[96][2];
#for(i, 0, 15)
    #declare edges[6*i][0] = tetrahedra[i][0];
    #declare edges[6*i][1] = tetrahedra[i][1];
    #declare edges[6*i+1][0] = tetrahedra[i][0];
    #declare edges[6*i+1][1] = tetrahedra[i][2];
    #declare edges[6*i+2][0] = tetrahedra[i][0];
    #declare edges[6*i+2][1] = tetrahedra[i][3];
    #declare edges[6*i+3][0] = tetrahedra[i][1];
    #declare edges[6*i+3][1] = tetrahedra[i][2];
    #declare edges[6*i+4][0] = tetrahedra[i][1];
    #declare edges[6*i+4][1] = tetrahedra[i][3];
    #declare edges[6*i+5][0] = tetrahedra[i][2];
    #declare edges[6*i+5][1] = tetrahedra[i][3];
#end

// rotated and projected vertices ----------------------------------------------
#macro rotate4d(theta, phi, xi, vec)
    #local a = cos(xi);
    #local b = sin(theta)*cos(phi)*sin(xi);
    #local c = sin(theta)*sin(phi)*sin(xi);
    #local d = cos(theta)*sin(xi);
    #local p = vec.x;
    #local q = vec.y;
    #local r = vec.z;
    #local s = vec.t;
    < a*p - b*q - c*r - d*s
    , a*q + b*p + c*s - d*r
    , a*r - b*s + c*p + d*q
    , a*s + b*r - c*q + d*p >
#end

#macro StereographicProjection(q, r2)
    acos(q.t/sqrt(r2))/pi/sqrt(r2-q.t*q.t) * <q.x,q.y,q.z>
#end

#macro Vertices3(theta, phi, xi, r2)
    #local out = array[nvertices];
    #for(i,0,nvertices-1)
        #local out[i] = StereographicProjection(
                            rotate4d(theta,phi,xi,vertices[i]), r2
                        );
    #end
    out
#end

/* macro spherical segment */
#macro vlength4(P)
    sqrt(P.x*P.x + P.y*P.y + P.z*P.z + P.t*P.t)
#end

#macro sphericalSegment(P, Q, r, n)
    #local out = array[n+1];
    #for(i, 0, n)
        #local pt = P + (i/n)*(Q-P);
        #local out[i] = r/vlength4(pt) * pt;
    #end
    out
#end

/* macro to draw an edge */
#macro Edge(verts, v1, v2, theta, phi, xi, r2, Tex)
    #local P = verts[v1];
    #local Q = verts[v2];
    #local PQ = sphericalSegment(P, Q, sqrt(r2), 100);
    sphere_sweep {
        b_spline 101
        #for(k,0,100)
            #local O =
                StereographicProjection(rotate4d(theta,phi,xi,PQ[k]), r2);
            O log(1+vlength(O)/4)/5
        #end
        texture {
            Tex
        }
    }
#end

/* stereographic subdivision (to fill the triangular faces) */
#macro midpoint4(A, B, r)
    #local xmid = (A.x + B.x)/2;
    #local ymid = (A.y + B.y)/2;
    #local zmid = (A.z + B.z)/2;
    #local tmid = (A.t + B.t)/2;
    #local lg = sqrt(xmid*xmid + ymid*ymid + zmid*zmid + tmid*tmid) / r;
    < xmid / lg, ymid / lg, zmid / lg, tmid / lg >
#end

#macro subdiv0(A, B, C, r)
    #local mAB = midpoint4(A, B, r);
    #local mAC = midpoint4(A, C, r);
    #local mBC = midpoint4(B, C, r);
    #local trgl1 = array[3] {A, mAB, mAC};
    #local trgl2 = array[3] {B, mAB, mBC};
    #local trgl3 = array[3] {C, mBC, mAC};
    #local trgl4 = array[3] {mAB, mAC, mBC};
    array[4] {trgl1, trgl2, trgl3, trgl4}
#end

#macro subdiv(A, B, C, r, depth)
    #if(depth=1)
        #local out = subdiv0(A, B, C, r);
    #else
        #local triangles = subdiv(A, B, C, r, depth-1);
        #local out = array[pow(4,depth)];
        #for(i, 0, pow(4,depth-1)-1)
            #local trgl = triangles[i];
            #local trgls = subdiv0(trgl[0], trgl[1], trgl[2], r);
            #local out[4*i] = trgls[0];
            #local out[4*i+1] = trgls[1];
            #local out[4*i+2] = trgls[2];
            #local out[4*i+3] = trgls[3];
        #end
    #end
    out
#end

/*-------------------------------------------*/
/*-----      draw the polychoron       ------*/
/*-------------------------------------------*/
#declare theta = pi/2;
#declare phi = 0;
#declare xi = 2*frame_number*pi/180;
#declare r2 = 3 + pow(1+sqrt(2),2);
#declare r = sqrt(r2);
#declare depth = 6;

#declare vs = Vertices3(theta, phi, xi, r2);

#declare stereoTriangles = array[64];
#for(i, 0, 63)
    #local triangles4 =
        subdiv(
            vertices[faces[i][0]],
            vertices[faces[i][1]],
            vertices[faces[i][2]], r, depth);
    #declare stereoTriangles[i] = array[dimension_size(triangles4,1)][3];
    #for(j, 0, dimension_size(triangles4,1)-1)
        #local trgl4 = triangles4[j];
        #declare stereoTriangles[i][j][0] =
            StereographicProjection(rotate4d(theta, phi, xi, trgl4[0]), r2);
        #declare stereoTriangles[i][j][1] =
            StereographicProjection(rotate4d(theta, phi, xi, trgl4[1]), r2);
        #declare stereoTriangles[i][j][2] =
            StereographicProjection(rotate4d(theta, phi, xi, trgl4[2]), r2);
    #end
#end

#declare edgeTexture = texture {
    pigment { color DarkPurple }
    finish {
        ambient 0.1
        brilliance 6
        diffuse 0.7
        metallic
        specular 0.80
        roughness 1/120
        reflection 0
    }
};

#declare meshTexture =
    texture {
        pigment { OrangeRed }
        finish {
            ambient 0.1
            diffuse 8
            brilliance 6
            metallic
            specular 0.80
            roughness 1/120
            reflection 0
        }
    };


object {
    union {
        /* draw edges */
        #for(i, 0, 95)
            Edge(vertices, edges[i][0], edges[i][1],
                    theta, phi, xi, r2, edgeTexture)
        #end
        /* draw vertices */
        #for(i, 0, 63)
            sphere {
                vs[i], log(1+vlength(vs[i])/4)/4
                texture { edgeTexture }
            }
        #end
        /* fill triangles */
        mesh {
            #for(i, 0, 63)
                #local trgl = stereoTriangles[i];
                #for(j, 0, dimension_size(trgl,1)-1)
                    triangle { trgl[j][0], trgl[j][1], trgl[j][2] }
                #end
            #end
            texture { meshTexture }
        }
     }
     scale 3.5
}
