Stereographic duoprism with Asymptote
This file contains bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
settings.render = 4; | |
settings.outformat = "eps"; | |
import tube; | |
size(200,0); | |
currentprojection=orthographic(4,4,4); | |
currentlight = light(gray(0.85), ambient=black, specularfactor=3, | |
(100,100,100), specular=gray(0.9), viewport=false); | |
currentlight.background = rgb("363940ff"); | |
// files to be saved ----------------------------------------------------------- | |
string[] files = { | |
"DP000", "DP001", "DP002", "DP003", "DP004", "DP005", | |
"DP006", "DP007", "DP008", "DP009", "DP010", "DP011", | |
"DP012", "DP013", "DP014", "DP015", "DP016", "DP017", | |
"DP018", "DP019", "DP020", "DP021", "DP022", "DP023", | |
"DP024", "DP025", "DP026", "DP027", "DP028", "DP029", | |
"DP030", "DP031", "DP032", "DP033", "DP034", "DP035", | |
"DP036", "DP037", "DP038", "DP039", "DP040", "DP041", | |
"DP042", "DP043", "DP044", "DP045", "DP046", "DP047", | |
"DP048", "DP049", "DP050", "DP051", "DP052", "DP053", | |
"DP054", "DP055", "DP056", "DP057", "DP058", "DP059", | |
"DP060", "DP061", "DP062", "DP063", "DP064", "DP065", | |
"DP066", "DP067", "DP068", "DP069", "DP070", "DP071", | |
"DP072", "DP073", "DP074", "DP075", "DP076", "DP077", | |
"DP078", "DP079", "DP080", "DP081", "DP082", "DP083", | |
"DP084", "DP085", "DP086", "DP087", "DP088", "DP089", | |
"DP090", "DP091", "DP092", "DP093", "DP094", "DP095", | |
"DP096", "DP097", "DP098", "DP099", "DP100", "DP101", | |
"DP102", "DP103", "DP104", "DP105", "DP106", "DP107", | |
"DP108", "DP109", "DP110", "DP111", "DP112", "DP113", | |
"DP114", "DP115", "DP116", "DP117", "DP118", "DP119", | |
"DP120", "DP121", "DP122", "DP123", "DP124", "DP125", | |
"DP126", "DP127", "DP128", "DP129", "DP130", "DP131", | |
"DP132", "DP133", "DP134", "DP135", "DP136", "DP137", | |
"DP138", "DP139", "DP140", "DP141", "DP142", "DP143", | |
"DP144", "DP145", "DP146", "DP147", "DP148", "DP149", | |
"DP150", "DP151", "DP152", "DP153", "DP154", "DP155", | |
"DP156", "DP157", "DP158", "DP159", "DP160", "DP161", | |
"DP162", "DP163", "DP164", "DP165", "DP166", "DP167", | |
"DP168", "DP169", "DP170", "DP171", "DP172", "DP173", | |
"DP174", "DP175", "DP176", "DP177", "DP178", "DP179"}; | |
// lexicographic order --------------------------------------------------------- | |
bool dominates(int[] e1, int[] e2){ | |
return e2[0]>e1[0] || (e2[0]==e1[0] && e2[1]>e1[1]); | |
} | |
// vertices -------------------------------------------------------------------- | |
int A = 8; | |
int B = 4; | |
struct quadruple { | |
real x; | |
real y; | |
real z; | |
real t; | |
} | |
real[][] poly1 = new real[A][2]; | |
for(int i = 0; i < A; ++i){ | |
poly1[i][0] = cos(i/A*2pi); | |
poly1[i][1] = sin(i/A*2pi); | |
} | |
real[][] poly2 = new real[B][2]; | |
for(int i = 0; i < B; ++i){ | |
poly2[i][0] = cos(pi/B+i/B*2pi); | |
poly2[i][1] = sin(pi/B+i/B*2pi); | |
} | |
quadruple[][] vertices = new quadruple[A][B]; | |
for(int i = 0; i < A; ++i){ | |
for(int j = 0; j < B; ++j){ | |
quadruple v; | |
v.x = poly1[i][0]; v.y = poly1[i][1]; | |
v.z = poly2[j][0]; v.t = poly2[j][1]; | |
vertices[i][j] = v; | |
} | |
} | |
// edges ----------------------------------------------------------------------- | |
int[][][] edges; | |
for(int i = 0; i < A; ++i){ | |
for(int j = 0; j < B; ++j){ | |
int[] e = {i,j}; | |
int[] candidate = {i,(j-1)%B}; | |
if(dominates(e,candidate)){ | |
int[][] edge = {e,candidate}; | |
edges.push(edge); | |
} | |
int[] candidate = {i,(j+1)%B}; | |
if(dominates(e,candidate)){ | |
int[][] edge = {e,candidate}; | |
edges.push(edge); | |
} | |
int[] candidate = {(i-1)%A,j}; | |
if(dominates(e,candidate)){ | |
int[][] edge = {e,candidate}; | |
edges.push(edge); | |
} | |
int[] candidate = {(i+1)%A,j}; | |
if(dominates(e,candidate)){ | |
int[][] edge = {e,candidate}; | |
edges.push(edge); | |
} | |
} | |
} | |
// rotation in 4D space (right-isoclinic) -------------------------------------- | |
quadruple rotate4d(real alpha, real beta, real xi, quadruple vec){ | |
real a = cos(xi); | |
real b = sin(alpha)*cos(beta)*sin(xi); | |
real c = sin(alpha)*sin(beta)*sin(xi); | |
real d = cos(alpha)*sin(xi); | |
real p = vec.x; | |
real q = vec.y; | |
real r = vec.z; | |
real s = vec.t; | |
quadruple out; | |
out.x = a*p - b*q - c*r - d*s; | |
out.y = a*q + b*p + c*s - d*r; | |
out.z = a*r - b*s + c*p + d*q; | |
out.t = a*s + b*r - c*q + d*p; | |
return out; | |
} | |
// stereographic projection ---------------------------------------------------- | |
triple stereog(quadruple A, real r){ | |
return (A.x, A.y, A.z) / (r - A.t); | |
} | |
// stereographic path ---------------------------------------------------------- | |
path3 stereoPath(quadruple A, quadruple B, real r, int n){ | |
path3 out; | |
for(int i = 0; i <= n; ++i){ | |
real t = i/n; | |
quadruple M; | |
real x = (1-t)*A.x + t*B.x; | |
real y = (1-t)*A.y + t*B.y; | |
real z = (1-t)*A.z + t*B.z; | |
real t = (1-t)*A.t + t*B.t; | |
real lg = sqrt(x*x + y*y + z*z + t*t) / r; | |
M.x = x / lg; M.y = y / lg; M.z = z / lg; M.t = t / lg; | |
out = out .. stereog(M, r); | |
} | |
return out; | |
} | |
// section transformation ------------------------------------------------------ | |
transform T(path3 p3, real t, int n){ | |
triple M = relpoint(p3, t/(n/4)); | |
return scale(length(M)/15); | |
} | |
// bounding box ---------------------------------------------------------------- | |
real f=3, h = 4.5, g = 1.5; | |
path3 boundingbox = (-h,0,-f)--(-h,0,g)--(h,0,f)--(h,0,-g)--cycle; | |
// draw the duoprism ----------------------------------------------------------- | |
int n = 100; | |
real r = sqrt(2); | |
real alpha = pi/2, beta = 0; | |
for(int file = 0; file < 180; ++file){ | |
real xi = 2*file*pi/180; | |
picture pic; | |
// draw bounding box | |
draw(pic, boundingbox, rgb("363940ff")+opacity(0)); | |
// draw edges | |
for(int k = 0; k < 2*A*B; ++k){ | |
quadruple A = vertices[edges[k][0][0]][edges[k][0][1]]; | |
quadruple B = vertices[edges[k][1][0]][edges[k][1][1]]; | |
path3 p3 = | |
stereoPath(rotate4d(alpha, beta, xi, A), rotate4d(alpha, beta, xi, B), r, n); | |
transform S(real t){ | |
return T(p3, t, n); | |
} | |
draw(pic, tube(p3, unitcircle, S), rgb(139,0,139), render(compression=Low,merge=true)); | |
} | |
// draw vertices | |
for(int i = 0; i < A; ++i){ | |
for(int j = 0; j < B; ++j){ | |
triple Asg = stereog(rotate4d(alpha, beta, xi, vertices[i][j]), r); | |
draw(pic, shift(Asg)*scale3(length(Asg)/10)*unitsphere, purple); | |
} | |
} | |
// add and save picture | |
add(pic); | |
shipout(files[file], bbox(rgb("363940ff"), FillDraw(rgb("363940ff")))); | |
erase(); | |
} |
Author
stla
commented
Jul 26, 2023
